A mechanical engineering student and specialized CAD designer focused on precision SolidWorks & Autodesk Inventor modeling, complex assemblies, AutoCAD drawings/Layouts and practical mechanical design solutions.

Ali Hassan

ALI
HASSAN

(Lets Chat!)

55+

Projects Completed

8+

Softwares & Tools

4

Internships Done

Selected Works & Expertise

Mechanical CAD Design Portfolio

A curated collection of specialized parametric models, structural weldments, advanced surface geometries, and plant assemblies.

Engineering Simulation

CFD & FEA Analysis Studies

Validating design integrity, fluid dynamics, and structural stress tolerances.

Technical Drawings

2D Engineering & Manufacturing Sheets

A comprehensive gallery of professional 2D manufacturing drawings modeled to precise ASME Y14.5 mechanical drafting norms.

GD&T Tolerancing

Controlled clearances and fits using datum features and feature control frames.

Orthographic Views

Standardized multi-view projections including precise sectional and detail cut sheets.

Weldments & Sheet Metal

Formal weld symbols, bevel preparations, sheet metal unfolding layouts, and bend tables.

Bill of Materials (BOM)

Comprehensive structural balloon callouts cross-referenced with cataloged assembly materials.

Technical Sheets Portfolio

Preview professional production-ready engineering blueprints.

TOTAL SHEETS: 12
ASME Y14.5 Technical Drawing Sheet
Assembly Drawing

Gearbox Assembly Section

Multi-view sectional cuts, BOM table, and specific surface finish callouts.

Sheet 01 View Blueprint ↗
ISO Standards Technical Drawing Sheet
Sheet Metal Unfolding

Enclosure Box Flat Pattern

Detailed flat pattern layout with bend allowance parameters and laser cutting paths.

Sheet 02 View Blueprint ↗
ASME Y14.5 Technical Drawing Sheet
Structural Weldment

Machinery Chassis Cut-List

Structural tube profiling, miter joint specs, and total stock length tables.

Sheet 03 View Blueprint ↗
ASME Y14.5 Technical Drawing Sheet
GD&T Tolerancing

Pneumatic Piston Detail Sheet

Datum references, position tolerances, thread callouts, and surface roughness specs.

Sheet 04 View Blueprint ↗
Services

Specialized Digital Offerings

I deliver top-tier mechanical designs, simulations, and engineering solutions, ensuring accurate structural validations and high-performance CAD models.

Parametric 3D CAD & Assemblies

Architecting production-ready parametric components, complex multi-part mechanisms, and fully constrained assembly structures.

Capabilities Include:
  • ✓ Advanced Part Modeling
  • ✓ Large Assembly Management
  • ✓ Exploded & Section Views
  • ✓ Design for Manufacture (DFM)

FEA & CFD Engineering Simulation

High-fidelity structural stress, thermal gradients, and fluid dynamics analysis to validate physical engineering systems.

Capabilities Include:
  • ✓ Finite Element Analysis (FEA)
  • ✓ Computational Fluid Dynamics (CFD)
  • ✓ Thermal & Stress Loading
  • ✓ Structural Weight Optimization

Advanced Surface Modeling

Creating complex aesthetic shapes, Class-A continuous curves, boundary surfaces, and ergonomic consumer product skins.

Capabilities Include:
  • ✓ Boundary & Lofted Surfaces
  • ✓ Curvature Continuity (G2/G3)
  • ✓ Complex Ergonomic Styling
  • ✓ Solid-Surface Thicken Ops

Mold Tools & Injection Molding

Designing production-grade core and cavity toolsets, parting lines, draft angle analysis, and multi-plate injection molds.

Capabilities Include:
  • ✓ Core & Cavity Extraction
  • ✓ Draft Angle & Undercut Analysis
  • ✓ Parting Line / Surface Setup
  • ✓ Side-Action Lifters & Sliders

Sheet Metal & Structural Weldments

Industrial framework design, tube routing, flat pattern unfolding, and laser-cutting compatible sheet metal enclosures.

Capabilities Include:
  • ✓ Cut-List Generation
  • ✓ Sheet Metal Flat Patterns
  • ✓ Structural Tube Profiling
  • ✓ Weldment Assembly & Gussets

2D Manufacturing & ASME Drawings

Precise production-ready technical drawings and layouts adhering strictly to ASME Y14.5 and ISO drawing standards.

Capabilities Include:
  • ✓ GD&T Feature Control Frames
  • ✓ Orthographic Projections
  • ✓ Bill of Materials (BOM) Tables
  • ✓ Sectional & Detail Cut Sheets
Contact

Start a Project Partnership

Have an idea, a product to develop, or a design challenge to solve? I can help transform your concept into accurate, functional, and manufacturing ready CAD designs.

Reach Out Directly

Have a project in mind or need professional assistance? Share the details through the form below, or reach out directly through your preferred communication channel.

Email Address alihassanx1412@gmail.com
WhatsApp Chat +92 335 0201251
Office Location Taxila, Pakistan (View on Map)
